引言

在前面的一篇文章PID控制算法简单说明了模糊控制算法的原理，本文用C++实现了一个通用性的模糊控制器。

fuzzy_controller.hpp文件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
#pragma once

#include <functional>
#include <map>
#include <string>
#include <vector>

namespace control_algorithm {

/**
 * @brief
 * 表示模糊集合的类，代表一个模糊集合，包含集合的名称和一个隶属度函数（该函数返回给定值的隶属度）。
 */
class FuzzySet {
 public:
  std::string name;                                  // 模糊集合的名称
  std::function<double(double)> membershipFunction;  // 隶属函数

  FuzzySet(const std::string& setName, std::function<double(double)> func)
      : name(setName), membershipFunction(func) {}

  double calculateMembership(double x) const { return membershipFunction(x); }
};

/**
 * @brief 模糊控制器类
 */
class Fuzzy {
 private:
  std::map<std::string, std::vector<FuzzySet>>
      inputVariables;                           // 输入变量及其模糊集合
  std::vector<FuzzySet> outputVariable;         // 输出变量的模糊集合
  std::map<std::string, std::string> ruleBase;  // 规则库

 public:
  Fuzzy();  // 构造函数

  void addInputVariable(const std::string& name,
                        const std::vector<FuzzySet>& sets);

  void setOutputVariable(const std::vector<FuzzySet>& sets);

  void addRule(const std::string& inputCondition,
               const std::string& outputAction);

  double evaluate(const std::map<std::string, double>& inputs);

 private:
  std::map<std::string, double> fuzzify(const std::string& variableName,
                                        double value);
  std::map<std::string, double> applyRules(
      const std::map<std::string, std::map<std::string, double>>&
          fuzzifiedInputs);

  double defuzzify(const std::map<std::string, double>& fuzzyOutput);
};

}  // namespace control_algorithm

fuzzy_controller.cpp文件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121

#include <cmath>
#include <iostream>
#include <numeric>
#include <stdexcept>

#include "fuzzy_controller.hpp"

using namespace control_algorithm;

Fuzzy::Fuzzy() {}

void Fuzzy::addInputVariable(const std::string& name,
                             const std::vector<FuzzySet>& sets) {
  inputVariables[name] = sets;
}

void Fuzzy::setOutputVariable(const std::vector<FuzzySet>& sets) {
  outputVariable = sets;
}

void Fuzzy::addRule(const std::string& inputCondition,
                    const std::string& outputAction) {
  ruleBase[inputCondition] = outputAction;
}

std::map<std::string, double> Fuzzy::fuzzify(const std::string& variableName,
                                             double value) {
  std::map<std::string, double> memberships;
  if (inputVariables.find(variableName) == inputVariables.end()) {
    throw std::invalid_argument("Unknown input variable: " + variableName);
  }

  for (const auto& set : inputVariables[variableName]) {
    memberships[set.name] = set.calculateMembership(value);
  }
  return memberships;
}

std::map<std::string, double> Fuzzy::applyRules(
    const std::map<std::string, std::map<std::string, double>>&
        fuzzifiedInputs) {
  std::map<std::string, double> aggregatedOutput;

  for (const auto& rule : ruleBase) {
    const std::string& inputCondition = rule.first;
    const std::string& outputAction = rule.second;

    // Split input conditions by " AND "
    double ruleActivation = 1.0;
    size_t start = 0;
    size_t end = inputCondition.find(" AND ");
    while (end != std::string::npos) {
      std::string variableAndSet = inputCondition.substr(start, end - start);
      size_t splitPos = variableAndSet.find(" ");
      std::string variable = variableAndSet.substr(0, splitPos);
      std::string set = variableAndSet.substr(splitPos + 1);

      // Check if input variable and set exist
      if (fuzzifiedInputs.count(variable) == 0 ||
          fuzzifiedInputs.at(variable).count(set) == 0) {
        ruleActivation = 0.0;
        break;
      }
      ruleActivation =
          std::min(ruleActivation, fuzzifiedInputs.at(variable).at(set));
      start = end + 5;  // Skip " AND "
      end = inputCondition.find(" AND ", start);
    }

    // Handle the last condition
    std::string variableAndSet = inputCondition.substr(start);
    size_t splitPos = variableAndSet.find(" ");
    std::string variable = variableAndSet.substr(0, splitPos);
    std::string set = variableAndSet.substr(splitPos + 1);

    if (fuzzifiedInputs.count(variable) == 0 ||
        fuzzifiedInputs.at(variable).count(set) == 0) {
      ruleActivation = 0.0;
    } else {
      ruleActivation =
          std::min(ruleActivation, fuzzifiedInputs.at(variable).at(set));
    }

    aggregatedOutput[outputAction] =
        std::max(aggregatedOutput[outputAction], ruleActivation);
  }

  return aggregatedOutput;
}

double Fuzzy::defuzzify(const std::map<std::string, double>& fuzzyOutput) {
  double numerator = 0.0;
  double denominator = 0.0;

  for (const auto& set : outputVariable) {
    double peak = 0.0;  // Replace with actual center of the fuzzy set
    // Approximation: assuming peak to be the mean of the set's universe
    double lowerBound = -200;  // Replace with the actual range
    double upperBound = 200;   // Replace with the actual range
    peak = (lowerBound + upperBound) / 2.0;

    if (fuzzyOutput.find(set.name) != fuzzyOutput.end()) {
      double membership = fuzzyOutput.at(set.name);
      numerator += peak * membership;
      denominator += membership;
    }
  }
  return denominator == 0 ? 0 : numerator / denominator;
}

double Fuzzy::evaluate(const std::map<std::string, double>& inputs) {
  std::map<std::string, std::map<std::string, double>> fuzzifiedInputs;

  for (const auto& input : inputs) {
    fuzzifiedInputs[input.first] = fuzzify(input.first, input.second);
  }

  auto fuzzyOutput = applyRules(fuzzifiedInputs);
  return defuzzify(fuzzyOutput);
}
